Thermally Controlled Exterior Bifold Patio Doors

The Aluminum Thermally Controlled Exterior Bifold Patio Doors are the result of an extensive design process focused on energy efficiency, structural integrity and versatility featuring a narrow 2 15/16" stile and rail profile with thermal breaks throughout for improved performance. Our proprietary core and fascia design allow for split finish color options for the interior and exterior providing maximum design flexibility.

Perfect for those climates where you want to keep either the cold or hot air out and the ideal temperature in. The Aluminum Thermally Controlled Exterior Bifold Patio Doors offer the sleek and contemporary design of our Aluminum system with improved thermal performance and added features.

Shop The Window Store’s selection of thermally controlled exterior bifold patio doors today to create a comfortable and beautiful space within your home.

Features

LaCantina Doors' Aluminum Thermally Controlled system is offered as a complete system with the following:

Perfect for hot & cold climates to keep the ideal temperature in
European thermal struts that create a non-conductive bridge between the outside and the inside of the door for greater energy efficiency
High quality extruded aluminum for strength & performance
Thicker 2 1/4" panels suitable for high wind environment
Proprietary core and fascia panel construction allows for a split finish option for different exterior and interior colors
Sill options that suit weather exposure or flush floor transitions from inside to outside
Custom simulated divided lite patterns
Stainless or bronze hardware packages
Concealed multi-point locking system for ease of operation and security
Single lite panels up to 10' tall without the need for a horizontal mullion
Clear & bronze anodized, and white in-stock finishes or create a distinctive color
3/8” to 11/4” triple glazing options
Unlimited configurations up to 65' wide
Up to 20 panels, 10 in each direction
Wide range of glazing options for ultimate thermal performance and safety protection
Inswing or outswing flexibility
DP 70 Impact Rated package available
Combine with our screen systems for year round comfort

Options Include

Wide range of configurations for design flexibility
90˚ zero post corners
Folding windows
Door & window combo
Kitchen servery pass through

Sizing & Configuration Options

The Aluminum Thermally Controlled bifold door system is available in a range of standard sizes to suit the most popular openings or can be "made to measure" up to 20 panels, 10 in each direction and 65' wide and 10' 4" tall. Contact us for other capabilities. Please click here for the complete configuration chart.

1L or 1R

2L or 2R

3L or 3R

2L1R or 1L2R

3L1R or 1L3R

2L2R

4L or 4R

5L or 5R

4L1R or 1L4R

3L2R or 2L3R

3L3R

5L1R or 1L5R

6L or 6R

Color Options

LaCantina Doors offer a wide range of in-stock, optional and custom colors. These color options will allow you to complement or match virtually almost any color for your project needs.

Clear Anodized

A wide range of the most popular colors in the marketplace today.

Fast Track White

LaCantina Doors offers custom color matching to virtually any color. A 2-coat 70% Kynar is the standard finish. Multi-coat, metallic and premium powder coat finishes can be specified for your project needs.

These 6 popular decoral wood grain powder coat finishes are also available.

Light Douglas Fir

Hardware

LaCantina Doors Folding System features the highest quality hardware and components for increased durability, ease of operation and smooth performance. This Folding System hardware is available with a multi-point lock in a stainless, bronze or black finish.

Exteior Handle

Stainless Steel

Glass Information

Dual glazed tempered glass is standard on all LaCantina Door systems. And our glass comes with a protective film to prevent your windows from getting scratched or damaged by dirt and debris. Simply remove the film once the project is completed.

For better energy performance, we feature low-E glass. Most commercially available glazing can be used, including tinted, obscure, laminated and single glazed. Laminated glass with SGP interlayer can be added for security or impact protection. In addition to our expansive range of glass options we offer Cardinal's latest innovation, Neat Glass designed to stay cleaner longer and reduce water spots in our low-E 270, 272 and 366 options. Should your project require customized glass please contact us to verify availability.
